CNC Tilting Two-spindle
|
||
High productivityTwo work-pieces can be machined simultaneously and cycle time can be shortened.
Light weight・CompactSuitable for small-sized machining centers
Outstanding water protectionAuto-Air Purging system (PAT.) is built in as standard and effects against coolant outstandingly. |
 |
■ Accurate indexing ■ Easy jig designing ■ Easy maintenance
Unit:mm
| Model | Left Handed | TNT130L-M2 | |
| Axis | Rotating Axis | Tiling Axis | |
| Table diameter | 130 | ― | |
| Table faucet hole diameter | 40H7 depth 15 | ― | |
| Table center through hole diameter | 25 | ― | |
| Table face height of rotating axis | 210 | ― | |
| Center height of tilting axis | ― | 150 | |
| Tilting range | ― | 110°〜−20° | |
| Distance between table centers | 150 | ||
| Clamp system | Air pressure (0.5 〜 0.7Mpa) | ||
| Clamp torque (N･ｍ) | 120 | 270 | |
| Indexing accuracy (Cumulative) | Within 30 sec. | Within 40 sec. | |
Allowable inertia moment per one axis (kg･m²) |
0.03 | ||
Allowable operation load |
Vertical load (N) | 3,500 | |
| Horizontal load (N･ｍ) | 145 | ||
Circumferential load (N･ｍ) |
65 | ||
| Total reduction ratio | 1/72 | 1/120 | |
| Maximum rotation (min-1) | 41.6 | 25 | |
| Guide piece width | 14h7 | ||
| Weight (kg) | 95 | ||
 |
||
| * | Guide piece (2pcs), Fixtures (2sets), Air tube (5m) for table clamping are attached. |
| * | Corresponding to Controller for CNC rotary table or to motor for additional axis. |
 |
